เครื่องดูดเศษขาอุปกรณ์ขณะตัด Lead Extractor C6002D

APPLICATIONS:
Cut Lead Extractor is used for cutting and shearing working station behind furnace, automatically absorbing cuttings of parts, so as to avoid cuttings falling on PCB plate and affecting product quality and 5S.
Cut Lead Extractor is an electronic component specially designed for cuttings and shearing recovering in the electronic industry. While shearing electronic parts, cutting leftover bits and pieces fly and bump with some force, which may fall into products or equipment, causing short circuit of products or damage workers’ eyes. This condition may cause harm to products and workers.

FEATURES:

• Each device can be equipped with 4-6 pipelines, each 2-m in length, with 4-6 cutting pliers.
• Air-taking diameter isφ75mm *2
• Adopt integration structure design with convenient installation, flexible movement, and no pipeline laid.
• Upper cover can be separately opened, convenient for pouring out parts bits and pieces, easy for maintenance.
• Good tightness is kept between the upper cover and machine body without leakage.
• The machine is equipped with ESD grounding connection and main power switch.
• Built-in DC brushless DC (330KW) with long life span, small noise, higher air mass flow.
• Internal parts of machine adopt F8 high-filtering ratio filtering element, which is dismountable and convenient for maintenance.
• Absorbing components parts reach to 99%.
• Dimensions: 400*300*360mm(L*W*H)
• Working absorbing force is more than 2500Pa.
• Air volume is more than 360 m3 per hour.
• Absorbing power of air volume is adjustable.
• Voltage AC 110-220V
• Weight 15KG
• Noise 45-70dB
